(2 PACK) FS1003 FLEETGUARD FUEL FILTER BF1293-SPS a109
Product Specifications
Condition: New
Brand: Fleetguard
Part Number: FS1003
Style: Spin-On Fuel/Water Separator Filter
Service: Fuel
Type: Full Flow
Media: Enhanced Cellulose
Height: 9.73 (247)*
Outer Diameter Top: 3.69 (94)*
Outer Diameter Bottom: Closed
Thread Size: 1-14
Burst Pressure-PSI: 200
Max Flow Rate: 12-15 GPM
Nominal Micron Rating: 8
( )* denotes metric
Gasket Diameters
O.D. I.D. Thk.
Attached 2.845 (72)* 2.500 (64)* 0.240 (6)*
Packed 1.29 (33)* 0.96 (24)* 0.218 (6)*
Principle Application
Various Cummins Engines. Has drain and sensor port. For high efficiency version, use FS19596. This sensor port is square with rounded corners. If oval shaped sensor port required use FS1022.
CAUTION: Furnished O-Ring must be installed on post for seal. For use with Deutz square sensor. NOT Interchangeable with FS1022.
Interchange Part Numbers
3604, 3406889, P551103, PS8687, FF1164-SPS, LFF1003, TP1027 95604, 86604, 86604XE, 87307432, 87307433, 4070801, FS1003B, FS19596, FSR81003, FSR819596, 22637904, WK9017X, 3604XE, 76195122, 87302104, F75915, J8621003, 33604, 33604XE, 533604XE
