All cross numbers listed will fit and seal. If you need more exact crossovers such as size or micron ratings message me. The crosses listed are only a guide if specifics don’t matter. Use the pictures shown as a help in determining if this filter is right for you.
We are a Baldwin and Fleetguard Filter distributor that purchases new filters directly from them. If you wish to purchase any filters you don’t see listed in our store, it’s possible we have them in stock, if not we can order the filters for you. We all want the best prices of anything we buy. If you see any new filters in our store that have a higher price than other stores you see online, send me a text. Filters are also sold locally that could limit availability of filters you see online.
If there are any filters we need to order or are short on stated inventory, I will text you personally and not from a robot. Please leave a cell phone as your contact. Otherwise, you will need to contact me for status. Contacting me by text is best way.
Filters ordered Friday, Saturday, Sunday and before 10am Monday will ship out on Tuesday.
Filters ordered Monday, Tuesday and Wednesday before 10am will ship out on Thursday.
Filters ordered Wednesday, Thursday before 10am will ship out on Friday.
If you have a shop and those darn filters are just collecting dust. Send me a list of filters you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters are the more I can offer.
Thank You for visiting AYP-Parts.
No Returns offered if the part is not correct without contacting us first before order is made with the part number you need. The cross-reference numbers listed are only as a guide. Any charts you see online may not be 100% correct. Some manufactures use the same part numbers but may be a different part. We will confirm that this part will work for you when you contact us.
(CASE OF 12) PF7748 BALDWIN FUEL FILTER FS19624 a342
Part Number: PF7748
Style: Cartridge Fuel Water Separator
Type: Full Flow
Media: Enhanced Cellulose
Height: 7” (178mm)*
Outer Diameter Top: 3.82” (97mm)*
Outer Diameter Bottom: Closed
Inside Diameter Top: Closed
Inside Diameter Bottom: 0.66” (17mm)*
Beta Ratio: 2/20/75=2/5/8
Nominal Micron Rating: 7
( )* denotes metric
O.D. I.D. Thk.
Packed 4.387” (111mm)* 4.109” (104mm)* 0.139” (4mm)*
Packed 1.762” (45mm)* 1.484” (38mm)* 0.139” (4mm)*
Packed 5.270” (134mm)* 4.850” (123mm)* 0.210” (5mm)*
High efficiency version of PF7744. Fuel Pro or Diesel Pro applied EleMax cartridge element with Stratapore media. 7 micron absolute rating, 98.7% efficient @ 100 gph (378 lph). Filter used with FH230 Fuel Pro & FH233 Diesel Pro Series Housings, Davco 382 & 233 Series Housings.
Interchange Part Numbers
PF7748 23529168 382114 P550467 382113 CS8744A 33651XE ABPN10GFS19624 86651XE L5467F A4720921205 102429 23533816 23533819 23538657 FSR819613 FF1127 FF1162 FS1962490 85106371 2191P550467 2588149C1 510795 60017381 SK3352 119953 FS550467 FS550796 85106371 102429 102529 382122 382130 23553381 FF1163 2588149C1 L5467F L5476FNXL L9721F 301SD19A 301SD19B 301SD19C F65973 33651
