Product Specifications
Condition: New
Brand: Fleetguard
Part Number: FF5632
Style: Spin-On Fuel Filter
Service: Fuel
Type: Full Flow
Media: Enhanced Cellulose
Height: 201.55 mm (7.935 in)
Outer Diameter Top: 93.17 mm (3.668 in)
Outer Diameter Bottom: Closed
Thread Size: M20 X 1.5-6H INT
Beta Ratio: B5=75
Max Flow Rate: 8-10 GPM
Nominal Micron Rating: 5
Filter Area: 688
Gasket Diameters
O.D. I.D. Thk.
Attached 2.83” (72mm)* 2.475” (63mm)* 0.225” (6mm)*
Interchange Part Numbers
4934845 BF7940 P550880 86682 73316835 84167233 84412164 84468410 84493919 87803199 87803200 87803208 21703110 4897897 4989106 1829166 FF5612 FF5790 BH1X9155AA P9454 9414101756 FF1174 SN40574 3978040 11LC70010 504292579 5801729418 SP125647 SP125671 LFF5421 LFF5632 WK929X 711853A1 3682 2124611 2852437 71102624 72130519 76615128 76615129 76615130 87621382 87622163 87622166 87803197 504043765 87803197MP MLR2124611 SK32972 FF550880 33682 580088512 42035598 -- BF7922 86682 73316835 84167233 84412164 84468410 84493919 87803199 87803200 87803208 21703110 4897897 4934845 4989106 1829166 FF5612 FF5790 BH1X9155AA P9454 9414101756 FF1174 SN40574 3978040 11LC70010 504292579 5801729418 SP125647 SP125671 LFF5421 LFF5632 WK929X 711853A1 3682 2124611 2852437 71102624 72130519 76615128 76615129 76615130 87621382 87622163 87622166 87803197 504043765 87803197MP MLR2124611 SK32972 P10715 F65942
Principle Application
Ford, Freightliner, Kenworth, Peterbilt, Sterling Trucks; Cummins ISB07 Stratapore Media. Goes on the pressure side of this engine. For the suction side use FS1065. For Upgrade, Use FF5812
All Applications
|
Make |
Model |
Year |
Engine |
|
APACHE+Sprayer |
AS1025 |
w / Cummins (Interim Tier IV) Engine |
|
|
AUTOCAR TRUCKS |
XPERT |
2011 - 2013 |
L6 6.7L 409 CID Cummins Turbo Diesel ISB |
|
AUTOCAR TRUCKS |
XSPOTTER |
2012 - 2016 |
L6 6.7L 409 CID Cummins Turbo Diesel ISB |
|
BLUE BIRD BUSES |
ALL AMERICAN (FORWARD ENGINE) |
2000 - 2007 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
ALL AMERICAN (FORWARD ENGINE) |
2007 - 2016 |
L6 6.7L 408 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
ALL AMERICAN (REAR ENGINE) |
1999 - 2007 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
ALL AMERICAN (REAR ENGINE) |
2007 - 2016 |
L6 6.7L 408 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
CONVENTIONAL BUS |
2012 - 2016 |
L6 6.7L 408 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
ULTRA LF |
2002 - 2007 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
ULTRA LMB |
2002 - 2005 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
VISION |
2007 - 2016 |
L6 6.7L 408 CID Cummins Turbo Diesel |
|
BLUE BIRD BUSES |
XCEL 102 (TRANSIT) |
2003 - 2003 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
CUMMINS TRUCK ENGINES |
ISB-07 (6.7L) |
||
|
CUMMINS TRUCK ENGINES |
ISB5.9 (5.9L) |
||
|
CUMMINS TRUCK ENGINES |
ISB6.7 (6.7) |
||
|
CUMMINS TRUCK ENGINES |
QSB6.7 |
||
|
CUMMINS+(Also See Consolidated+Engines) |
ISB07 |
||
|
CUMMINS+(Also See Consolidated+Engines) |
ISB6.7 (6.7L) |
||
|
CUMMINS+(Also See Consolidated+Engines) |
QSB6.7 |
||
|
CUMMINS+(Also See Consolidated+Engines) |
QSB6.7 (6.7L) TIER IV |
||
|
DINA |
PICKER |
w / Cummin ISB-07 (6.7L) Engine |
|
|
DYNAPAC+Rollers |
CC7200 |
L 6 6.7L 408 CID |
|
|
FORD TRUCKS |
F650 |
2008 - 2013 |
L 6 6.7L 408 CID |
|
FORD TRUCKS |
F650 |
2000 - 2008 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
FORD TRUCKS |
F750 |
2008 - 2013 |
L 6 6.7L 408 CID |
|
FORD TRUCKS |
F750 |
2000 - 2008 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
FREIGHTLINER TRUCKS & BUSES |
B2 CHASSIS |
2007 - 2017 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
C2 CHASSIS |
2004 - 2011 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
CARGO |
1999 - 2007 |
L6 5.9L 5883CC 359CID |
|
FREIGHTLINER TRUCKS & BUSES |
FB65 CHASSIS |
2007 - 2010 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
FC70 |
2000 - 2004 |
L6 5.9L 5883CC 359CID |
|
FREIGHTLINER TRUCKS & BUSES |
FS65 |
2008 - 2008 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
M2 106 |
2008 - 2016 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
M2E |
2008 - 2008 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
MB 45 |
1998 - 2000 |
L6 5.9L 5883CC 359CID |
|
FREIGHTLINER TRUCKS & BUSES |
MC-L CHASSIS |
1999 - 2002 |
L6 5.9L 5883CC 359CID |
|
FREIGHTLINER TRUCKS & BUSES |
MT45 CHASSIS |
2010 - 2016 |
L6 6.7L 6735CC 411CID |
|
FREIGHTLINER TRUCKS & BUSES |
MT55 CHASSIS |
2011 - 2017 |
L6 6.7L 6735CC 411CID |
|
HAGIE+Sprayers |
STS10 HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS10C HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS10T HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS12 HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS12C HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS12I HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS12IC HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS14 HI-TRACROR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HAGIE+Sprayers |
STS14C HI-TRACTOR |
w / Cummins Diesel QSB6.7 Tier IV Eng. |
|
|
HYUNDAI+Loaders |
HL760-9A |
w / Cummins QSB6.7 (Interim Tier IV) Engine |
|
|
KAWASAKI+Loaders |
80Z7 |
L6 6.7L 6700CC 409CID |
|
|
KENWORTH TRUCKS |
K270 |
2012 - 2016 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
KENWORTH TRUCKS |
K370 |
2012 - 2016 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
KENWORTH TRUCKS |
T170 |
2008 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
KENWORTH TRUCKS |
T270 |
2008 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
KENWORTH TRUCKS |
T370 |
2008 - 2011 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PACCAR |
PX-6 SERIES (6.7L) |
||
|
PETERBILT TRUCKS |
210 |
2008 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PETERBILT TRUCKS |
320 |
2009 - 2009 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PETERBILT TRUCKS |
325 |
2008 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PETERBILT TRUCKS |
330 |
2007 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PETERBILT TRUCKS |
330 |
2008 - 2010 |
L6 6.7L 408 CID Paccar Turbo Diesel/Electric |
|
PETERBILT TRUCKS |
335 |
2007 - 2010 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
PETERBILT TRUCKS |
335 |
2008 - 2010 |
L6 6.7L 408 CID Paccar Turbo Diesel/Electric |
|
PETERBILT TRUCKS |
337 |
2010 - 2013 |
L6 6.7L 408 CID Paccar Turbo Diesel |
|
STERLING TRUCKS |
ACTERRA |
2008 - 2009 |
L6 6.7L 6691CC 408CID |
|
STERLING TRUCKS |
SC8000 |
1999 - 2007 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
STERLING TRUCKS |
SC8000 |
2007 - 2009 |
L6 6.7L 6691CC 408CID |
|
THOMAS BUSES |
SAF-T-LINER |
2009 - 2009 |
L6 5.9L 359 CID Cummins Turbo Diesel |
|
THOMAS BUSES |
SAF-T-LINER |
2008 - 2011 |
L6 6.7L 408 CID Cummins Turbo Diesel |
|
TIGER CAT+Equipment |
234B |
L 4 4.5L |
|
|
TIGER CAT+Equipment |
620E |
L 6 6.7L |
|
|
TIGER CAT+Equipment |
845D |
L 6 6.7L |
|
|
TIGER CAT+Equipment |
L845D |
L 6 6.7L |
This case of filters is a non-stocking item. When you place the order, I will order from Fleetguard then send the case to you. Most of the time I receive orders in 1-3 business days. Once received the case will be sent to you next business day.
All cross numbers listed will spin on and seal. If you need more exact crossovers such as size or micron ratings message me. The crosses listed are only a guide if specifics don’t matter. Use the pictures shown as a help in determining if this filter is right for you.
