(CASE OF 6) FS19764 FLEETGUARD FUEL FILTER for Davco Fuel Processors 380/382 a025
Product Specifications
Condition: New
Brand: Fleetguard
Part Number: FS19764
Style: Cartridge Fuel Metal Canister Filter
Service: Fuel
Type: Full Flow
Media: Enhanced Cellulose
Height: 7.039” (179mm)*
Outer Diameter: 4.21” (107mm)*
Inside Diameter Top: Closed
Inside Diameter Bottom: 0.66” (17mm)*
Nominal Micron Rating: 10
( )* denotes metric
Gasket Diameters
O.D. I.D. Thk.
Packed (O-Ring) 1.761” (45mm)* 1.489” (38mm)* 0.136” (3mm)*
Packed (O-Ring) 5.1” (130mm)* 4.69” (119mm)* 0.205” (5mm)*
Principle Application
Plus size version of FS19727 for Extended Service Intervals when used in FH230 Series Fuel Pro's or standard for FH234 Series Industrial Pro.
Interchange Part Numbers
PF9814 P550849 86964 L9763FXL 3964 FS550849 33964 102526 102527 5580012785 5580007857 4669642
|
Make |
Model |
Year |
Engine |
|
AUTOCAR TRUCKS |
XPEDITOR |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
CUMMINS TRUCK ENGINES |
ISX11.9 (11.9L) |
||
|
CUMMINS TRUCK ENGINES |
ISX15 (450) (15.0L) |
||
|
CUMMINS+(Also See Consolidated+Engines) |
ISX11.9 (11.9L) |
||
|
CUMMINS+(Also See Consolidated+Engines) |
ISX12 |
||
|
CUMMINS+(Also See Consolidated+Engines) |
ISX15 (450) (15.0L) |
||
|
CUMMINS+(Also See Consolidated+Engines) |
QSM12 (12L) TIER IV FINAL |
||
|
CUMMINS+(Also See Consolidated+Engines) |
QSX15 (15L) TIER IV FINAL |
||
|
FREIGHTLINER TRUCKS & BUSES |
122SD |
2014 - 2016 |
L6 15L 15000cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
CASCADIA |
2010 - 2016 |
L6 15L 15000cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
CENTURY CLASS, CENTURY CLASS S/T, C112, CST112, C120, CST120 |
2000 - 2003 |
L 6 14.9L 14994cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
CLASSIC, CLASSIC XL |
2001 - 2003 |
L 6 14.9L 14994cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
COLUMBIA, CL112, CL120 |
2001 - 2003 |
L 6 14.9L 14994cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
CORONADO, CC122, CC132 |
2000 - 2003 |
L 6 14.9L 14994cc 915 CID |
|
FREIGHTLINER TRUCKS & BUSES |
CORONADO, CC122, CC132 |
2010 - 2016 |
L6 15L 15000cc 915 CID |
|
IHC/NAVISTAR TRUCKS |
9900I |
2012 - 2014 |
L6 14.9L 915 CID Cummins |
|
IHC/NAVISTAR TRUCKS |
LONESTAR |
2012 - 2016 |
L6 14.9L 915 CID Cummins |
|
IHC/NAVISTAR TRUCKS |
PAYSTAR 5900I |
2012 - 2014 |
L6 14.9L 915 CID Cummins |
|
IHC/NAVISTAR TRUCKS |
PROSTAR |
2012 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
C500 SERIES |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
C550 SERIES |
2011 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
C550 |
2010 - 2011 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
T440 |
2010 - 2013 |
L 6 8.3L 8275cc 505 CID |
|
KENWORTH TRUCKS |
T440 |
2010 - 2013 |
L6 8.9L 543 CID Cummins |
|
KENWORTH TRUCKS |
T470 |
2010 - 2013 |
L 6 8.3L 8275cc 505 CID |
|
KENWORTH TRUCKS |
T470 |
2010 - 2013 |
L6 8.9L 543 CID Cummins |
|
KENWORTH TRUCKS |
T470H |
2009 - 2009 |
L6 8.9L 543 CID Cummins |
|
KENWORTH TRUCKS |
T660 |
2009 - 2016 |
L6 11.9L 726 CID Cummins |
|
KENWORTH TRUCKS |
T660 |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
T680 |
2013 - 2016 |
L6 11.9L 726 CID Cummins |
|
KENWORTH TRUCKS |
T680 |
2013 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
T700 |
2010 - 2015 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
T800 SERIES |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
KENWORTH TRUCKS |
T800 SERIES |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
T880 |
2012 - 2018 |
L6 11.9L 726 CID Cummins |
|
KENWORTH TRUCKS |
T880 |
2013 - 2016 |
L6 14.9L 915 CID Cummins |
|
KENWORTH TRUCKS |
W900 SERIES |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
KENWORTH TRUCKS |
W900 SERIES |
2010 - 2018 |
L6 14.9L 915 CID Cummins |
|
MACK TRUCKS |
GU4 SERIES (GRANITE) |
2012 - 2017 |
L6 8.9L 661 543 Cummins |
|
MACK TRUCKS |
GU5 SERIES (GRANITE) |
2012 - 2016 |
L6 8.9L 661 543 Cummins |
|
MACK TRUCKS |
MHD (GRANITE) |
2012 - 2014 |
L6 8.9L 661 543 Cummins |
|
MCI (Motor Coach Industries) |
D4505 |
2012 - 2013 |
L6 11.9L 726 CID Cummins |
|
MCI (Motor Coach Industries) |
J4500 |
2012 - 2014 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
320 |
2013 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
357 |
1997 - 2006 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
365 |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
365 |
2010 - 2016 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
367 |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
367 |
2013 - 2016 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
379 |
1997 - 1998 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
379X |
1997 - 1998 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
382 |
2011 - 2015 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
384 |
2010 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
384 |
2011 - 2016 |
L6 8.9L 540 CID Cummins Turbo Diesel |
|
PETERBILT TRUCKS |
386 |
2010 - 2015 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
387 |
2010 - 2012 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
388 |
2010 - 2012 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
388 |
2010 - 2015 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
389 |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
567 |
2013 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
567 |
2013 - 2016 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
579 |
2013 - 2016 |
L6 11.9L 726 CID Cummins |
|
PETERBILT TRUCKS |
579 |
2013 - 2016 |
L6 14.9L 915 CID Cummins |
|
PETERBILT TRUCKS |
587 |
2011 - 2016 |
L6 14.9L 915 CID Cummins |
|
VOLVO TRUCKS |
VN, VNL SERIES |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
VOLVO TRUCKS |
VNM SERIES |
2010 - 2016 |
L6 14.9L 915 CID Cummins |
|
VOLVO TRUCKS |
VT SERIES |
2010 - 2010 |
L6 14.9L 915 CID Cummins |
|
WESTERN STAR TRUCKS |
4900EX |
2002 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900FA |
2002 - 2015 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900SA |
2002 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900SB |
2012 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900SF |
2012 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900TS |
2012 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
4900XD |
2012 - 2016 |
L6 14.9L 14900CC 915CID |
|
WESTERN STAR TRUCKS |
6900XD |
2010 - 2013 |
L6 14.9L 14900CC 915CID |
All cross numbers listed will fit and seal. If you need more exact crossovers such as micron ratings message me. The crosses listed are only a guide if specifics doesn't matter. Use the pictures shown as a help in determining if this filter is right for you.
AYP-PARTS
We are a Fleetguard Filter distributor that purchases new filters directly from Fleetguard filters from stores going out of business or old inventory stores want to get rid of. Filters listed as New Old Stock can be from any brand name that are not purchased as New. Some filters may have OE boxes, seals, or plastic wrap missing. Some may even have slight dings or minor surface rust. I do throw away filters I would not recommend using. If any filter has any rust or dings I will inform you and show pictures. If I feel the filter will be ok to use I will list them. We also purchase cases of brand new Fleetguard filters under special pricing for our eBay customers that wishes us to stock and long as they are a common filter that sells on eBay. We also offer volume discounts on new cases of Fleetguard Filters. If you control inventory for a shop and want to get ready for a new season, send be a message or contact me for a discount. In turn you will get the lowest prices anywhere. If you wish to purchase a case of Fleetguard filters you don’t see listed in my store most likely I can order these filters for you and give a volume discount also. All brand-new filters will be sold by the case. All filters of other brands will all be crossed to the Fleetguard filter they represent and sold by that part number in a lot. We all want the best prices of anything we buy. If you see any filters in my store that is not a Fleetguard filter that you need but has a higher price than any other filter you see in eBay, keep coming to the store. Every month price drops at least $1.00 or up to $10.00 until it reaches $0.99. If you see your item disappear from your watch list, come back to store. Could mean price was lowered. Also, if you see someone else selling a filter lower than mine that is listed as New Old Stock I will beat their price by 10%. Just send a message you found one cheaper and I’ll find the listing.
We also have several parts that are new or used from Honda vehicles or other makes. Soon we will be a source of many used auto parts. All used parts will be cleaned and if possible tested to insure they work. Stay tuned for more parts to come.
We do purchase new and old inventory and also Honda vehicles that will be sold for parts. If you have a shop and those darn filters are just collecting dust, or Honda’s rotting away in the back message me. Send me a list of filters, parts or Honda’s you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters and vehicles look the more I offer.
Thank You for visiting AYP-Parts.
No Returns offered if the part is not correct without contacting us first before order is made with the part number you need. The cross reference numbers listed are only as a guide. Any charts you see listed even if they are provided by eBay may not be 100% correct. Some manufactures use the same part numbers but may be a different part. We will confirm that this part will work for you when you contact us.
