(CASE OF 6) FS19684E FLEETGUARD FUEL FILTER a190

Sale price $77.99 Regular price $131.46

(CASE OF 6) FS19684E FLEETGUARD FUEL FILTER a190

Product Specifications
Condition: New
Brand: Fleetguard
Part Number: FS19684E
Style: Cartridge Fuel Metal Free Filter
Service: Fuel
Type: Full Flow
Media: Enhanced Cellulose
Height: 5.59 (142)*
Outer Diameter Top: 3.69 (94)*
Outer Diameter Bottom: 3.6 (91)*
Inside Diameter Top: Closed:
Inside Diameter Bottom: 0.82 (21)*
Nominal Micron Rating: 7
( )* denotes metric

Gasket Diameters
             O.D.          I.D.             Thk.
Packed 4.5 (114)* 4.25 (108)* 0.125 (3)*
Packed 2.93 (74)* 2.76 (70)*   0.085 (2)*

Principle Application
IHC Trucks w/DT466, DT466E, DT570, HT570 Engines (05-on)

Interchange Part Numbers
PF7779 1842638C91 P550657 86719 FS19684 FSR819684 CS9970 FF1159 L9684F 2191P550657 3719 1822638C91 1842638C92 F55966 FS550657 33719 1841393C1

All Applications

Make

Model

Year

Engine

BLUE BIRD BUSES

CONVENTIONAL BUS

2005 - 2005

L6 7.6L 466 CID International Turbo Diesel

CHAMPION BUSES

DEFENDER DF270

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF280

w / Maxxforce DT (7.6L) Engine

CHAMPION BUSES

DEFENDER DF290

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF310

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF350

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF380

w / International DT466 (7.6L) Engine

IC BUSES

CE SERIES (PB105)

2003 - 2009

L6 7.6L 466 CID IHC Turbo Diesel DT466

IC BUSES

FE SERIES

2003 - 2006

L6 7.6L 466 CID IHC Turbo Diesel DT466

IC BUSES

RE SERIES (PB305)

2007 - 2007

L6 7.6L 466 CID IHC Turbo Diesel DT466

IHC/NAVISTAR

DT466 (7.6L) (2005-ON)

IHC/NAVISTAR

DT466E (7.6L) (1996-ON)

IHC/NAVISTAR

DT466HD (7.6L) (2005-ON)

IHC/NAVISTAR

DT570 (9.3L)

IHC/NAVISTAR

HT570 (9.3L)

IHC/NAVISTAR

MAXXFORCE 9 (9.3L)

IHC/NAVISTAR

MAXXFORCE DT (7.6L)

IHC/NAVISTAR TRUCKS

3000 SERIES

2005 - 2006

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

4000 SERIES

2002 - 2008

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

4000 SERIES

2002 - 2016

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

7000 SERIES

2005 - 2007

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

7000 SERIES

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

8500

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

8600

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

CXT

2005 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

CXT

2006 - 2008

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2010

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2014

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

RXT

2006 - 2008

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

TRANSTAR 8500

2008 - 2009

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2008 - 2009

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2008 - 2009

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2008 - 2009

L6 9.3L 570 CID Turbo Diesel

These filters are a stocking item.  Sometimes however, we do run out but when ordered if we do not have them in stock, we will order directly from Fleetguard then send the filters to you.  Most of the time I receive orders in 1-3 business days from Fleetguard.  Once received the filters will be sent to you next business day.  If you are in a hurry message me and we will check inventory.

All cross numbers listed will spin on and seal.  If you need more exact crossovers such as size or micron ratings message me.  The crosses listed are only a guide if specifics don’t matter.  Use the pictures shown as a help in determining if this filter is right for you.
