BF7760 (CASE OF 12) BALDWIN FUEL FILTER FF2203 for Kenworth & Peterbilt ISX Engines a633

All cross numbers listed will fit and seal.  If you need more exact crossovers such as size or micron ratings message me.  The crosses listed are only a guide if specifics don’t matter.  Use the pictures shown as a help in determining if this filter is right for you.

AYP-PARTS

We are a Baldwin and Fleetguard Filter distributor that purchases new filters directly from them.  If you wish to purchase any filters you don’t see listed in our store, it’s possible we have them in stock, if not we can order the filters for you.  We all want the best prices of anything we buy. If you see any new filters in our store that have a higher price than other stores you see online, send me a text.  Filters are also sold locally that could limit availability of filters you see online.

If there are any filters we need to order or are short on stated inventory, I will text you personally and not from a robot.  Please leave a cell phone as your contact.  Otherwise, you will need to contact me for status.  Contacting me by text is best way.

Filters ordered Friday, Saturday, Sunday and before 10am Monday will ship out on Tuesday.

Filters ordered Monday, Tuesday and Wednesday before 10am will ship out on Thursday.

Filters ordered Wednesday, Thursday before 10am will ship out on Friday.

If you have a shop and those darn filters are just collecting dust. Send me a list of filters you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters are the more I can offer.

Thank You for visiting AYP-Parts.

No Returns offered if the part is not correct without contacting us first before order is made with the part number you need.  The cross-reference numbers listed are only as a guide.  Any charts you see online may not be 100% correct.  Some manufactures use the same part numbers but may be a different part.  We will confirm that this part will work for you when you contact us.

(CASE OF 12) BF7760 BALDWIN FUEL FILTER FF2203 for Kenworth & Peterbilt ISX Engines a633

Product Specifications
Condition: New
Brand: Baldwin
Part Number: BF7760
Style: Spin-On Fuel Filter
Service: Fuel
Type: Full Flow
Media: Wire Mesh
Height: 5.78” (147mm)*
Outer Diameter Top: 3.72” (94mm)*
Outer Diameter Bottom: Closed
Thread Size: 1-14
Max Flow Rate: 12-15 GPM
Nominal Micron Rating: 140
( )* denotes metric

Gasket Diameters
               O.D.                 I.D.                  Thk.
Attached 2.83” (72mm)* 2.46” (62mm)* 0.17” (4mm)*

Interchange Part Numbers

BF7760 P552203 86691 LFF2203 FFR82203 P10272 4010476 2191P552203 85114079 ABP/N10GFF2203 FF1128 3691 F65983 33691

Principle Applications
Kenworth, Peterbilt, IHC Trucks with ISX Cummins Engines

All Applications
