(CASE OF 6) LF691A FLEETGUARD OIL FILTER Case Caterpillar Challenger Ford Mack a218
Part Number: LF691A
Style: Spin-On Lube Filter
Type: Full Flow
Media: Enhanced Cellulose
Height: 12.184” (309mm)*
Outer Diameter Top: 5.342” (136mm)*
Outer Diameter Bottom: Closed
Thread Size: 1 1/2-16
By-Pass Valve Setting-PSI: None
Beta Ratio: 2/20=8/21
Burst Pressure-PSI: 300
Max Flow Rate: 28-30 GPM
Nominal Micron Rating: 19
( )* denotes metric
O.D. I.D. Thk.
Attached 4.320” (110mm)* 3.820” (97mm)* 0.365” (9mm)*
Interchange Part Numbers
92792 85792 LFP4005 X871096 XLF2000 LFR8691A 9576P554005 DNP554005 LF282 HDA15005 5218323 AT82193 KW691 4425274 2191P554005 FL326 1792 Y05017412 L65236 QS3335 103854 12706480 121482001 1R0716 2P4005 PF879 715065 ABPN10GLF691A 3130937 12335 1663805C1 SP1028 WD13145 B99 P554005 PH3335 51792 HPH3335FP PH3426 TPH3335FP PF2101 PF879L AML691 PL691 122211 OC21060 SFO4005 SDF73 SP425 52183233 3216165500 3216953103 ABP3001574 SWT603043 E6739 92792MP 92792XD 92792XE 1457434131 V012941 60034329 85792 85792MP 2721788 2722788 81531209 81561209 1W2660 2P4005 2Y8097 3I0731 3I1284 4W6000 7W5497 8T7452 IR0716 LFP4005 PH4005 HO508 7255400500 3PS5189 3632030 TL2CS0 TL2CSO TL2FSO TLSFSO X871096 X871191 DO935 AZL128 9334 XLF2000 PM518 434 WD434 499074 4425274 Y1022 1002065 69002783 6201041024 40035123 OC21060 SFO0691 SFO4005 FT4940 ZP538 A309Y 9334 LFR8691A LFR89691A NL309 PL691 Y05017412 9576P554005 DNP554005 DNP554105 FO1288 GP52 GP52M GP691 P518 9058S 9058S1 9414100363 2240141 G051792 7650143 Z184 3095171 FP359 LF282 LF282XS P359 HD0351 HD3850 A15005 HDA15005 H300W04 H300WD01 2P4005 SO10017 SO691 CV102763 5218323 35362235 38480810 52183233 92036219 2P4005 AT82193 45495 52763112 KL800020 KW691 LW691 OC122 4425274 FB99 KL190 L1904 L190R L190RMO L190RU AP77501 AP77501A LK77501 LK97500 25021 499144274 LFP4005HE LFP4005XL MDL5004 2191P554005 KFO0332594 OC122 PC230MIC25 PC230SM10 499074 51055040066 51055040067 W131452 WD13125 WD131451 29245330 FL326 FL326FP 1792 1792MP 14528 103854 1499396 BC1085 BC1085A Y05017412 PMX400510 PMX4005109H A69 1R716 AF1309 19502495 LS846 H65040 L65236 PC204 PC230 PC230MIC10 PC230MIC25 PER70 QS3335 LUS4005 HDZ235 Z235 C5502 C55021 9120126 69002783 330560279 85693 SP4459 SPH21012 CV518 RES4005 12335 136904 68562224OLD SFO0691 SFO4005 1002065 69002783 PS405 PSL405 R89 103854 HDO13 L01700 1W2660 4W6000 7W5497 8T7452 12706480 12706480 2341200 88808 374714 688808 T081075 121482001 LF554005 3130937 172015003 811025 811407 199395 1877 71486 51792 551792 51792MP WGL3374 WGL691 WGL691R WGL9137 PF2101 PF2101F PF879 SDF73 6027 3216165500 3222317948 ABP3001574 SWT603043 2630063000 12335 1R0716 1R1808 1W2660 2721788 2P4005 2Y8097 3I1284 3I1293 4W6000 7W5497 8T7452 HO508 3PS5189 3632030 1808074 TL2FSO DO935 T081075 AZL128 9334 PM518 WD434 00499074 04425274 4425274 499074 PF2101 PF879 40035123 FT4940 LFR8691 PL691 H541225M26 12490136 25014776 6439658 GP52 GP691 GP52 GP52M 9414100363 7650143 Z184 FP359 FP360 LF282XS LF359 HDA15005 H300W04 H300WD01 1663805C1 3014491C91 52183233 92036219 52763112 HP8002 619790 KW691 LW691 OC122 OC124 L190 L190R L206 499144274 LFP4005TRT W13145 W131452 WD13145 WD131451 MPL883 L60069 PHM3335A 29245330 FL326 294000125954 2940001259544 85402A 103854 1499396 BC1085 FO73 PLF4005 K50010 L50070 L60069 L65236 L65969 HDZ235 330560279 085693 85693 187898 SFS06207B CV518 012335 12335 158882 00953 0953 953 SFO0691 SFO1459 SFO4005 PSL405 HDO13 2341200 T081075 121482001 172015003 3430937 3945425 199395 1877 51792MP 51792XD WGL691
Caterpillar Engines - standard version - for high efficiency microglass media, use LF9691A
All cross numbers listed will spin on and seal. If you need more exact crossovers such as size or micron ratings message me. The crosses listed are only a guide if specifics don’t matter. Use the pictures shown as a help in determining if this filter is right for you.
We are a Fleetguard Filter distributor that purchases new filters directly from Fleetguard filters from stores going out of business or old inventory stores want to get rid of. Non Fleetguard filters can be from any brand name that are not purchased as New. Some filters may have OE boxes, seals, or plastic wrap missing. Some may even have slight dings or minor surface rust. I do throw away filters I would not recommend using. If any filter has any rust or dings, I will inform you and show pictures. If I feel the filter will be ok to use, I will list them. We also purchase cases of brand new Fleetguard filters to keep in stock under special pricing for our customers that wishes us to stock, as long as they are common filters that sell. We also offer volume discounts on multiple cases of Fleetguard filters. If you control inventory for a shop and want to get ready for a new season, send be a message or contact me for a discount. In turn you will get the lowest prices anywhere. If you wish to purchase a case of Fleetguard filters you don’t see listed in my store most likely I can order these filters for you also. All Fleetguard are sold by the case unless smaller lots are shown. All filters of other brands will all be crossed and grouped together to the Fleetguard filter they represent and sold by that part number in a lot. We all want the best prices of anything we buy. If you see any filters or parts in my store that have a higher price than other stores you see in online, send me a message.
We also have several parts that are new or used from Honda vehicles or other makes. Soon we will be a source of many used auto parts. All used parts will be cleaned and if possible tested to insure they work. Stay tuned for more parts to come.
We do purchase new and old inventory and also vehicles that will be sold for parts. If you have a shop and those darn filters are just collecting dust, or cars rotting away in the back message me. Send me a list of filters, parts or cars you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters and vehicles look the more I offer.
Thank You for visiting AYP-Parts.
No Returns offered if the part is not correct without contacting us first before order is made with the part number you need. The cross-reference numbers listed are only as a guide. Any charts you see online may not be 100% correct. Some manufactures use the same part numbers but may be a different part. We will confirm that this part will work for you when you contact us.
