BD7250 (CASE OF 6) BALDWIN OIL FILTER LF9025 DT466E DT570 HT570 Maxxforce a566 R

Sale price $199.99 Regular price $365.85

Baldwin is having supply issues for filling orders on this filter.  We have many of these filters ordered.  We are line to receive them.  Once it is our turn, they will ship what is available.  If you subscribe to our website, you will be notified when they become in stock or can be ordered.  Customers that already made the purchase we will ship to them first.  If any filters are left, subscribers will be notified.  If you have any questions, please send me a text at 636-887-6799.



All cross numbers listed will spin on and seal.  If you need more exact crossovers such as size or micron ratings message me.  The crosses listed are only a guide if specifics don’t matter.  Use the pictures shown as a help in determining if this filter is right for you.

                                                        AYP-PARTS

We are a Baldwin and Fleetguard Filter distributor that purchases new filters directly from them.  We also purchase filters from stores going out of business or old inventory stores want to get rid of. If you wish to purchase any filters you don’t see listed in our store most likely I can order these filters for you. All Baldwin and Fleetguard filters are sold by the case unless smaller lots are shown. If you don’t need a full case message us and we may be able to sell lesser quantities.  We all want the best prices of anything we buy. If you see any new filters in the store that have a higher price than other stores you see in online, send me a message.

If there are any filters, we need to order, that does not have a message in bold above on supply issues you will be sent a personal text so leave a cell number as your contact.  If I have time, I will update you every week or two on progress or you can send me a text at 636-887-6799.

If you have a shop and those darn filters are just collecting dust. Send me a list of filters you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters are the more I can offer.

Thank You for visiting AYP-Parts.


No Returns offered if the part is not correct without contacting us first before order is made with the part number you need.  The cross-reference numbers listed are only as a guide.  Any charts you see online may not be 100% correct.  Some manufactures use the same part numbers but may be a different part.  We will confirm that this part will work for you when you contact us.


(CASE OF 6) BD7250 BALDWIN OIL FILTER LF9025 DT466E DT570 HT570 Maxxforce a566

Product Specifications
Condition: New
Brand: Baldwin
Part Number: BD7250
Style: Spin-On Lube Filter
Service: Lube
Type: Full Flow/By-Pass
Media: Microglass
Height: 13.67” (347mm)*
Outer Diameter Top: 4.68” (119mm)*
Outer Diameter Bottom: Closed
Thread Size: 95X2.0mm
By-Pass Valve Setting-PSI: None
Burst Pressure-PSI: 305
Max Flow Rate: 39 GPM
Nominal Micron Rating: 35
( )* denotes metric

Interchange Part Numbers
LFP9025 PH9971 PH9971A 57744XD P552025 LF597 7744 LF552025 1842639C91 1841606C1 BD7250 2191P550656 57744 7744XD P550656 84744XD HP8025 L65965 84744 LF902500

Principle Application
IHC Trucks w/ DT466E, DT570, HT570, MaxxForce Engines (05-on)

All Applications

Make

Model

Year

Engine

BLUE BIRD BUSES

CONVENTIONAL BUS

2005 - 2005

L6 7.6L 466 CID International Turbo Diesel

CHAMPION BUSES

NAVISTAR DF270

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF280

w / Maxxforce DT (7.6L) Engine

CHAMPION BUSES

DEFENDER DF290

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF310

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF350

w / International DT466 (7.6L) Engine

CHAMPION BUSES

DEFENDER DF380

w / International DT466 (7.6L) Engine

IC BUSES

CE SERIES (PB105)

2003 - 2009

L6 7.6L 466 CID IHC Turbo Diesel DT466

IC BUSES

CE SERIES (PB105)

2010 - 2011

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IC BUSES

HC SERIES

2010 - 2011

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IC BUSES

RE SERIES (PB305)

2010 - 2011

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IHC/NAVISTAR

DT466 (7.6L) (2005-ON)

IHC/NAVISTAR

DT466E (7.6L) (1996-ON)

IHC/NAVISTAR

DT466HD (7.6L) (2005-ON)

IHC/NAVISTAR

DT570 (9.3L)

IHC/NAVISTAR

HT570 (9.3L)

IHC/NAVISTAR

MAXXFORCE 10 (9.3L)

IHC/NAVISTAR

MAXXFORCE 9 (9.3L)

IHC/NAVISTAR

MAXXFORCE DT (7.6L)

IHC/NAVISTAR TRUCKS

4000 SERIES

2002 - 2008

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

4000 SERIES

2002 - 2008

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

7000 SERIES

2002 - 2007

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

7000 SERIES

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

8500

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

8600

2005 - 2007

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

CXT

2006 - 2008

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2016

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2016

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2010

V8 6.4L 389 CID

IHC/NAVISTAR TRUCKS

RXT

2006 - 2008

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

TRANSTAR 8500

2008 - 2012

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2008 - 2016

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2008 - 2017

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2008 - 2009

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2008 - 2016

L6 9.3L 570 CID Turbo Diesel
