All cross numbers listed will spin on and seal. If you need more exact crossovers such as size or micron ratings message me. The crosses listed are only a guide if specifics don’t matter. Use the pictures shown as a help in determining if this filter is right for you.
AYP-PARTS
We are a Baldwin and Fleetguard Filter distributor that purchases new filters directly from them. We also purchase filters from stores going out of business or old inventory stores want to get rid of. If you wish to purchase any filters you don’t see listed in our store most likely I can order these filters for you. All Baldwin and Fleetguard filters are sold by the case unless smaller lots are shown. If you don’t need a full case message us and we may be able to sell lesser quantities. We all want the best prices of anything we buy. If you see any new filters in the store that have a higher price than other stores you see in online, send me a message.
If there are any filters, we need to order, that does not have a message in bold above on supply issues you will be sent a personal text so leave a cell number as your contact. If I have time, I will update you every week or two on progress or you can send me a text at 636-887-6799.
If you have a shop and those darn filters are just collecting dust. Send me a list of filters you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters are the more I can offer.
Thank You for visiting AYP-Parts.
No Returns offered if the part is not correct without contacting us first before order is made with the part number you need. The cross-reference numbers listed are only as a guide. Any charts you see online may not be 100% correct. Some manufactures use the same part numbers but may be a different part. We will confirm that this part will work for you when you contact us.
(4 PACK) BD7169 BALDWIN OIL FILTER LF3807 Chevrolet GMC Isuzu Tiltcab a062
Product Specifications
Condition: New
Brand: Baldwin
Part Number: BD7169
Style: Spin-On Lube Filter
Service: Lube
Type: Full Flow/By-Pass
Media: Enhanced Cellulose
Height: 5.04 (128)*
Outer Diameter Top: 4.668 (119)*
Outer Diameter Bottom: Closed
Thread Size: 1 1/2-12
By-Pass Valve Setting-PSI: 19
Burst Pressure-PSI: 320
Max Flow Rate: 28-30 GPM
Nominal Micron Rating: 22
( )* denotes metric
Gasket Diameters
O.D. I.D. Thk.
Attached 4.32 (110)* 3.8 (97)* 0.365 (9)*
Principle Application
Various Isuzu Diesel Engines, GM "W" Series Tilt-Cabs
Interchange Part Numbers
BD7169 97148270 2906548000 8971482700 P502042 57521 IO3319 IO3322 91521 84521 C1562 FO1077 GP359 LF507 92956285 5873104880 5873104881 8943381810 8943381811 8970967770 8971482701 8973713340 L7521 LFP5964 WP1240 T6757 7521 L35495 J8610077 J8610181 Z476 Z767 C1515 C1519 SF518 SFO6777 SFO8181 C711 C7111 C518 LF502046 PF947L 92673 ELF7947 LFR83632 R7521 25014120 94338181 97046464 97049282 97096777 97136470 97719921 LF273 LF281 LF505 AL6354 2906546000 8970464641 8970492820 8971364700 8971482800 LFP2339 L30279 L46066 CFS1215 LO1206K
All Applications
|
Make |
Model |
Year |
Engine |
|
BOGDAN |
A |
A-064 |
|
|
BOGDAN |
A |
A-091 |
|
|
BOGDAN |
A |
A-092/A-092.2 |
|
|
CHEVROLET TRUCKS & BUSES |
W3500 TILTMASTER |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
CHEVROLET TRUCKS & BUSES |
W3500 TILTMASTER |
2005 - 2009 |
L4 5.2L 5200cc 317 CID |
|
CHEVROLET TRUCKS & BUSES |
W4 |
1999 - 2002 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
CHEVROLET TRUCKS & BUSES |
W4500 TILTMASTER |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
CHEVROLET TRUCKS & BUSES |
W4500 TILTMASTER |
2005 - 2010 |
L4 5.2L 5200cc 317 CID |
|
CHEVROLET TRUCKS & BUSES |
W5500 TILTMASTER |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
CHEVROLET TRUCKS & BUSES |
W5500 TILTMASTER |
2005 - 2009 |
L4 5.2L 5200cc 317 CID |
|
CHEVROLET TRUCKS & BUSES |
W5500HD TILTMASTER |
2004 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
CHEVROLET TRUCKS & BUSES |
W5500HD TILTMASTER |
2005 - 2009 |
L4 5.2L 5200cc 317 CID |
|
GMC TRUCKS & BUSES |
W3500 FORWARD |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W3500 FORWARD |
2005 - 2009 |
L4 5.2L 317 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W4 |
1999 - 2002 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W4500 FORWARD |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W4500 FORWARD |
2005 - 2010 |
L4 5.2L 317 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W5500 FORWARD |
1999 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W5500 FORWARD |
2005 - 2009 |
L4 5.2L 317 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W5500HD FORWARD |
2004 - 2004 |
L4 4.8L 290 CID Isuzu Turbo Diesel |
|
GMC TRUCKS & BUSES |
W5500HD FORWARD |
2005 - 2009 |
L4 5.2L 317 CID Isuzu Turbo Diesel |
|
ISUZU TRUCKS |
ELF 400 |
2007 - 2017 |
L4 5.2L 317 CID Turbo Diesel Isuzu |
|
ISUZU TRUCKS |
ELF 450 |
2006 - 2008 |
L4 5.2L 317 CID Turbo Diesel Isuzu |
|
ISUZU TRUCKS |
ELF 500 |
2012 - 2017 |
L4 5.2L 317 CID Turbo Diesel Isuzu |
|
ISUZU TRUCKS |
ELF 600 |
2013 - 2017 |
L4 5.2L 317 CID Turbo Diesel Isuzu |
|
ISUZU TRUCKS |
N SERIES |
1998 - 2004 |
L4 4.8L 290 CID Turbo Diesel |
|
ISUZU TRUCKS |
N SERIES |
2005 - 2017 |
L4 5.2L 317 CID Turbo Diesel |
|
ISUZU+Engines |
4HE1-TC (4.8L) |
||
|
ISUZU+Engines |
4HE1-XS (4.8L) |
||
|
ISUZU+Engines |
4HE1T (4.8L) |
||
|
ISUZU+Engines |
4HF1T |
||
|
ISUZU+Engines |
4HG1 |
||
|
ISUZU+Engines |
4HJ1 |
||
|
ISUZU+Engines |
4HK1-TC (5.2L) DIESEL |
||
|
ISUZU+World Trucks |
ELF 400 |
2012 - 2012 |
L4 5.2L 5193cc Turbo Diesel |
|
ISUZU+World Trucks |
ELF 400 |
2007 - 2009 |
w / HK1-T Engine |
|
ISUZU+World Trucks |
ELF 450 |
L4 5.2L 5193cc Turbo Diesel |
|
|
ISUZU+World Trucks |
ELF 500 |
2012 - 2012 |
L4 5.2L 5193cc Turbo Diesel |
|
ISUZU+World Trucks |
ELF 500 |
2007 - 2009 |
w / HK1-T Engine |
|
ISUZU+World Trucks |
ELF 600 |
2012 - 2012 |
L4 5.2L 5193cc Turbo Diesel |
|
ISUZU+World Trucks |
ELF 600 |
2007 - 2009 |
w / HK1-T Engine |
|
ISUZU+World Trucks |
ELF250 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
ELF250 |
w / Isuzu 4HG1 Engine |
|
|
ISUZU+World Trucks |
ELF250 |
w / Isuzu 4HK1TC (5.2L) Engine |
|
|
ISUZU+World Trucks |
ELF250 (4600 SERIES) |
w / Isuzu 4HG1 Engine |
|
|
ISUZU+World Trucks |
ELF250 (4800 SERIES) |
w / Isuzu 4HF1T Engine |
|
|
ISUZU+World Trucks |
ELF350 |
w / Isuzu 4.6L Engine |
|
|
ISUZU+World Trucks |
FORWARD 800 |
L4 5.2L 5193cc Turbo Diesel |
|
|
ISUZU+World Trucks |
KC-NKR66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
KC-NKR66 |
w / Isuzu 4HF1T Engine |
|
|
ISUZU+World Trucks |
KC-NPR71 |
w / Isuzu 4HG1 Engine |
|
|
ISUZU+World Trucks |
KC-NPR72 |
w / Isuzu 4HG1 Engine |
|
|
ISUZU+World Trucks |
KC-NPR72 |
w / Isuzu 4HJ1 Engine |
|
|
ISUZU+World Trucks |
NKR150 |
w / Isuzu 4HF1 (SiTEC 110) Engine |
|
|
ISUZU+World Trucks |
NKR200 |
w / Isuzu 4HF1 (SiTEC 110) Engine |
|
|
ISUZU+World Trucks |
NKR66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
NPR250 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
NPR300 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
NPR350 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
NPR400 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
NPR66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
U-NKR66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
U-NKR66 |
w / Isuzu 4HF1T Engine |
|
|
ISUZU+World Trucks |
U-NPR66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
U-NPR66 |
w / Isuzu 4HF1T Engine |
|
|
ISUZU+World Trucks |
U-NPR70 |
w / Isuzu 4HF1T Engine |
|
|
ISUZU+World Trucks |
U-NPS66 |
w / Isuzu 4HF1 (4.3L) Engine |
|
|
ISUZU+World Trucks |
U-NPS66 |
w / Isuzu 4HF1T Engine |
