LF17499 (2 PACK) FLEETGUARD OIL FILTER B7503 for Maxx Force DT 9 & 10 Engines a671

Sale price $135.99 Regular price $215.87

All cross numbers listed will spin on and seal.  If you need more exact crossovers such as size or micron ratings message me.  The crosses listed are only a guide if specifics don’t matter.  Use the pictures shown as a help in determining if this filter is right for you.

                                                       AYP-PARTS

We are a Baldwin and Fleetguard Filter distributor that purchases new filters directly from them.  We also purchase filters from stores going out of business or old inventory stores want to get rid of. If you wish to purchase any filters you don’t see listed in our store most likely I can order these filters for you. All Baldwin and Fleetguard filters are sold by the case unless smaller lots are shown. If you don’t need a full case message us and we may be able to sell lesser quantities.  We all want the best prices of anything we buy. If you see any new filters in the store that have a higher price than other stores you see in online, send me a message.

If there are any filters, we need to order, that does not have a message in bold above on supply issues you will be sent a personal text so leave a cell number as your contact.  If I have time, I will update you every week or two on progress or you can send me a text at 636-887-6799.

If you have a shop and those darn filters are just collecting dust. Send me a list of filters you have and how much you are asking and your location. I will look up part numbers you send to find the wholesale value and send an offer to you. The more presentable the filters are the more I can offer.

Thank You for visiting AYP-Parts.


No Returns offered if the part is not correct without contacting us first before order is made with the part number you need.  The cross-reference numbers listed are only as a guide.  Any charts you see online may not be 100% correct.  Some manufactures use the same part numbers but may be a different part.  We will confirm that this part will work for you when you contact us.


(2 PACK) LF17499 FLEETGUARD OIL FILTER B7503 for Maxx Force DT 9 & 10 Engines a671

Product Specifications
Condition: New
Brand: Fleetguard
Part Number: LF17499
Style: Spin-On Lube Filter
Service: Lube
Type: Full Flow
Media: Microglass
Height: 11.362” (289mm)*
Outer Diameter Top: 4.668” (119mm)*
Outer Diameter Bottom: Closed
Thread Size: 1 3/4-12
By-Pass Valve Setting-PSI: 30
Beta Ratio: B20=10
Nominal Micron Rating: 10
( )* denotes metric

Gasket Diameters
               O.D.                   I.D.                  Thk.
Attached 4.32” (110mm)* 3.82” (97mm)* 0.365” (9mm)*

Interchange Part Numbers
B7503 P551145 84708 LFP6035 7708 57708 1884508C1 1884508C2 1889124C91

Principle Application
Various IHC Trucks w/DT-466 Maxx Force Engine (11-on)

Make

Model

Year

Engine

IC BUSES

CE SERIES (PB105)

2011 - 2012

L6 7.6L 466 CID IHC Turbo Diesel Hybrid MaxxForce DT

IC BUSES

CE SERIES (PB105)

2010 - 2016

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IC BUSES

FE SERIES

2007 - 2008

L6 7.6L 466 CID IHC Turbo Diesel DT466

IC BUSES

FE SERIES

2008 - 2008

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IC BUSES

HC SERIES

2010 - 2011

L6 7.6L 466 CID IHC Turbo Diesel Hybrid MaxxForce DT

IC BUSES

HC SERIES

2010 - 2011

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IC BUSES

RE SERIES (PB305)

2010 - 2012

L6 7.6L 466 CID IHC Turbo Diesel MaxxForce DT

IHC/NAVISTAR

MAXXFORCE 10 (9.3L)

IHC/NAVISTAR

MAXXFORCE DT (7.6L)

IHC/NAVISTAR TRUCKS

DURASTAR

2008 - 2016

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

DURASTAR

2012 - 2016

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

TRANSTAR 8500

2010 - 2012

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2007 - 2016

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7300

2010 - 2016

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2010 - 2016

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7400

2010 - 2017

L6 9.3L 570 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2010 - 2014

L6 7.6L 466 CID Turbo Diesel

IHC/NAVISTAR TRUCKS

WORKSTAR 7500

2010 - 2016

L6 9.3L 570 CID Turbo Diesel
